| Ink | |
| Number of Nozzles | Total 1,792 nozzles |
| Ink Bottles (Type / Colours) | GI-71 (Pigment / Black), (Dye-Based Ink / Cyan, Magenta, Yellow) |
| Maintenance Cartridge | MC-G02 |
| Maximum Printing Resolution | 4,800 (horizontal)*1Â x 1,200 (vertical) dpi |
| Print Speed*2(Approx.)
Based on ISO/IEC 24734 |
|
| Document (ESAT/Simplex) | 9.1 / 5 ipm (mono/colour) |
| Document (FPOT Ready/Simplex) | 9 / 16 sec (mono/colour) |
| Photo (4 x 6″) (PP-201/Borderless) | 45 sec |
| Printable Width | Up to 203.2 mm (8″) Borderless: Up to 216 mm (8.5″) |
| Printable Area | |
| Borderless Printing*3 | Top/Bottom/Left/Right margin: each 0 mm |
| Bordered Printing | Envelope (COM10/DL): Top margin: 8 mm, Bottom margin: 12.7 mm, Left/Right margin: 3.4 mm Envelopes (C5/Monarch): Square 5 x 5″ (127 x 127 mm): Square 3.5 x 3.5″ (89 x 89 mm): LTR/LGL/Foolscap/B-Oficio: M-Oficio: Others: |
| Support Media | |
| Rear Tray | Plain Paper (64-105 g/m²) Photo Paper Pro Luster (LU-101) Photo Paper Plus Glossy II (PP-201/PP-208) Matte Photo Paper (MP-101) Double Sided Matte Paper (MP-101D) Glossy Photo Paper “Everyday Use” (GP-508) High Resolution Paper (HR-101N) Photo Paper Plus Semi-Gloss (SG-201) Photo Stickers (PS-208/PS-808) Envelope |
| Paper Size | |
| Rear Tray | A4, A5, A6, B5, LTR, LGL, Executive (184.2 x 266.7 mm), Legal (India) (215 x 345 mm), Foolscap (215.9 x 330.2 mm), F4 (215.9 x 330.2 mm), Oficio2 (215.9 x 330.2 mm), B-Oficio (216 x 355 mm), M-Oficio (216 x 341 mm), 4 x 6″, 5 x 7″, 7 x 10″, 8 x 10″, Envelopes DL, Envelopes COM10, Envelopes C5, Envelopes Monarch (98.4 x 190.5 mm), Square (3.5 x 3.5”, 5 x 5”), Card Size (91 x 55 mm)
Custom size: |
| Paper Size (Borderless)*4 | A4, LTR, 4×6″, 5×7″, 7×10″, 8×10″ Square (3.5 x 3.5″, 5 x 5″), Card Size (91 x 55 mm) |
| Paper Handling (Maximum Number) | |
| Rear Tray | Plain Paper (A4, 64 g/m²) = 100 High Resolution Paper (HR-101N) = 80 Photo Paper Plus Glossy II (PP-201, 4 x 6″) = 20 Photo Paper Plus Semi-Gloss (SG-201, 4 x 6″) = 20 Glossy Photo Paper “Everyday Use” (GP-508, 4 x 6″)=20 Matte Photo Paper (MP-101, 4 x 6″) = 20 |
| Paper Weight | |
| Rear Tray | Plain Paper: 64-105 g/m² Canon paper: Max paper weight: approx. 275 g/m² (Photo Paper Plus Glossy II, PP-201) |
| Ink End Sensor | Dot count type |
| Print Head Alignment | Manual |
Scan*5
| Scanner Type | Flatbed |
| Scanner Method | CIS (Contact Image Sensor) |
| Optical Resolution*6 | 600 x 1,200 dpi |
| Scanning Bit Depth (Input/Output) | |
| Grayscale | 16 bit/8 bit |
| Colour | RGB each 16 bit/8 bit |
| Line Scanning Speed*7 | |
| Grayscale | 1.5 ms/line (300 dpi) |
| Colour | 3.5 ms/line (300 dpi) |
| Maximum Document Size | |
| Flatbed | A4/LTR |
Copy
| Maximum Document Size | A4/LTR |
| Compatible Media | |
| Size | A4, A5, A6, B5, LTR, LGL, Executive (184.2 x 266.7 mm), Legal (215 x 345 mm), Foolscap (215.9 x 330.2 mm), B-Oficio (216 x 355 mm), M-Oficio (216 x 341 mm), 4 x 6″, 5 x 7″, Square (5 x 5″), Card Size (91 x 55 mm) |
| Type | Plain Paper Photo Paper Plus Glossy II (PP-201, PP-208) Photo Paper Pro Luster (LU-101) Photo Paper Plus Semi-Gloss (SG-201) Matte Photo Paper(MP-101) Glossy Photo Paper(GP-508) |
| Image Quality | 3 positions (Economy, Standard, High) |
| Density Adjustment | 9 positions, Auto intensity (AE copy) |
| Copy Speed*8(Approx.)
Based on ISO/IEC 24734 |
|
| Document (Colour): (sFCOT/Simplex) / (sESAT/Simplex) | 28 sec / 2.6 ipm |
| Multiple Copy | |
| Mono/Colour | Max. 99 pages |
Network
| Protocol | SNMP, HTTP, TCP/IP (IPv4/IPv6) |
| Wireless LAN | |
| Network Type | IEEE802.11b/g/n |
| 2.4GHz Channel (1 – 11) | US/HK/TW/LTN/BR/CAN |
| 2.4GHz Channel (1 – 13) | JP/KR/EUR/AU/ASA/CN/EMBU |
| Security | WEP 64/128 bit WPA-PSK (TKIP/AES) WPA2-PSK (TKIP/AES) |
| Direct Connection (Wireless LAN) | Available |
Printing Solutions
| AirPrint | Available |
| Mopria | Available |
| Canon Print Service (for Android) |
Available |
| PIXMA Cloud Link From smartphone or tablet |
Available |
| Easy Photo-Print Editor (for iOS/Android) |
Available |
| Canon PRINT Inkjet/SELPHY (for iOS/Android) |
Available |
| Camera Direct | Wireless LAN |
System Requirements*9
| Windows 10 / 8.1 / 7 SP1 (operation can only be guaranteed on a PC with a pre-installed Windows 7 or later) macOS 10.12.6 ~ 10.15 Chrome OS |
General Specifications
| Operation Panel | |
| Display | 2-Line LCD |
| Language | 32 Selectable Languages: Japanese / English / German / French / Italian / Spanish / Dutch / Portuguese / Norwegian / Swedish / Danish / Finnish / Russian / Czech / Hungarian / Polish / Slovene / Turkish / Greek / Simplified Chinese / Traditional Chinese / Korean / Indonesian / Slovakian / Estonian / Latvian / Lithuanian / Ukrainian / Romanian / Bulgarian / Thai / Croatian / Vietnamese |
| Interface | USB 2.0 |
| PictBridge (Wireless) | Available |
| Operating Environment*10 | |
| Temperature | 5 – 35°C |
| Humidity | 10 – 90% RH (no dew condensation) |
| Recommended Environment*11 | |
| Temperature | 15 – 30°C |
| Humidity | 10 – 80% RH (no dew condensation) |
| Storage Environment | |
| Temperature | 0 – 40°C |
| Humidity | 5 – 95% RH (no dew condensation) |
| Quiet Mode | Available |
| Acoustic Noise (PC Print) (Approx.) | |
| Plain Paper (A4, B/W)*12 | 49.5 dB(A) |
| Power | AC 100-240 V, 50/60 Hz |
| Power Consumption (Approx.) | |
| OFF | 0.2 W |
| Standby (scanning lamp is off) USB connection to PC |
0.6 W |
| Copying*13 USB connection to PC |
16 W |
| Duty Cycle | Up to 3,000 pages/month |
| Dimensions (WxDxH) (Approx.) | |
| Factory Configuration | 445 x 330 x 167 mm |
| Output/ADF Trays Extended | 445 x 555 x 238 mm |
| Weight (Approx.) | 6.4 kg |
Page Yield
| Plain Paper (A4 pages) (ISO/IEC 24712 test file)*14 |
Standard: GI-71 PGBK: 6,000 GI-71 C, M, Y: 7,700*15 GI-71S PGBK: 3,100 Economy*16: GI-71S PGBK: 3,900 |
| Photo Paper (PP-201, 4 x 6″) (ISO/IEC 29103 test file)*14 |
Standard: GI-71 PGBK: NA*17 GI-71 C, M, Y: 2,200 GI-71S PGBK: NA*17 |
